LED downlight
Recessed Led Down Light Linear Spot for Supermarket
Key attributes
Packaging and delivery
Ratings & Reviews
Supplier
LightSeek is a professional LED lighting manufacturer specializing in track lights, downlights, and commercial lighting solutions. With in-house R&D, production, and quality control, we serve retail, supermarket, museum, and hospitality projects worldwide. Our products are backed by up to 5 years warranty and strict quality standards.
Product descriptions
Recessed Led Down Light Linear Spot for Supermarket
| Technical Data | ||||||
| Model number | DL-3W01-L01 | DL-9W01-L01 | DL-15W01-L01 | DL-30W01-L01 | DL-12W01-L01 | DL-27W01-L01 |
| Watt | 3W | 9W | 15W | 30W | 12W | 27W |
| Sizes (mm) | L51.5*W51.5*H56 | L127*W51.5*H56 | L203*W51.3*H56 | L393*W51.5*H56 | L90*W90*H56 | L128*W128*H56 |
| Input voltage | 180-240V AC/100-277V AC | |||||
| Light effect (lm/W) |
100lm/W | |||||
| CRI | 80 Ra/ 90 Ra/ 97 Ra | |||||
| CCT | 2200K/2700K/3000K/4000K/5000K/6000K | |||||
| Beam angle | 15°, 24°, 38°, 50°, 50°*50°, 70°*70°, 35°*70°Asymetric | |||||
| Bright attennat | <3% (per year) | |||||
| Dimmable | Triac dimming/0-10V dimming/Dali dimming for choices | |||||
| Flicker free | YES | |||||
| Insallation | Recessed | |||||
| Housing color | black, white, grey | |||||
| Warranty | 5 Years | |||||
Projects
Hot Sale
Frequently Asked Questions
What warranty does the Recessed Led Down Light Linear Spot for Supermarket come with?
The Recessed Led Down Light Linear Spot for Supermarket carries a 5-year warranty with full coverage and no pro-rating. It is built with Tier-1 chips (Philips, Bridgelux, OSRAM) and an isolated constant-current driver with 4kV surge protection.
Can the Recessed Led Down Light Linear Spot for Supermarket be customized for OEM/ODM projects?
Yes. LightSeek offers full OEM/ODM for the Recessed Led Down Light Linear Spot for Supermarket — including CCT, CRI, power, finish, beam angle, and dimming protocol — backed by 3D prototyping, 24-hour aging tests, and CE/UL/SAA certification support.
What color temperature is the Recessed Led Down Light Linear Spot for Supermarket available in?
The Recessed Led Down Light Linear Spot for Supermarket is available in 2700K (Soft Warm White), 3500K (Warm White), 4100K (Neutral White), 5000K (Daylight), 6000K (Daylight Alert). 2700K–3000K suits warm hospitality ambiance, 4000K is typical for neutral retail and office environments, and 5000K+ for task-critical areas.
What is the CRI of the Recessed Led Down Light Linear Spot for Supermarket?
The Recessed Led Down Light Linear Spot for Supermarket has a CRI of 90. Ra≥80 is acceptable for general commercial use, Ra≥90 for retail and display lighting, and Ra≥95 with R9>50 for museums and premium galleries.
What beam angle does the Recessed Led Down Light Linear Spot for Supermarket have?
The Recessed Led Down Light Linear Spot for Supermarket has a other beam angle. ≤18° for accent and spotlighting, 18–36° for general lighting, and ≥36° for wide wash.
