LED downlight
Commercial Indoor Ceiling IP20 8w 12w 15w 20w 25w 30w 40w 45w Surface Mounted Cylinder Spotlight Led Downlight
Key attributes
Packaging and delivery
Ratings & Reviews
Supplier
LightSeek is a professional LED lighting manufacturer specializing in track lights, downlights, and commercial lighting solutions. With in-house R&D, production, and quality control, we serve retail, supermarket, museum, and hospitality projects worldwide. Our products are backed by up to 5 years warranty and strict quality standards.
Product descriptions
Commercial Indoor Ceiling IP65 8w 12w 15w 20w 25w 30w 40w 45w Surface Mounted Cylinder Spotlight Led Downlight
 |
Technical Data | |||||
| Model number | SDL-7W-R02 | SDL-15W-R02 | SDL-20W-R02 | SDL-30W-R02 | SDL-40W-R02 | |
| Watt | 7W | 15W | 20W | 30W | 40W | |
| Sizes | D90*H90mm | D110*H120mm | D130*H152mm | D170*H185mm | D193*H193mm | |
| Input voltage | 180-240V AC/100-277V AC | |||||
| Light effect (lm/W) |
100lm/W | |||||
| CRI | 80 Ra/ 90 Ra/ 97 Ra | |||||
| CCT | 2200K/2700K/3000K/4000K/5000K/6000K | |||||
| Beam angle | 20°/45° | |||||
| Bright attennat | <3% (per year) | |||||
| Dimmable | Triac dimming/0-10V dimming/Dali dimming for choices | |||||
| Flicker free | YES | |||||
| Insallation | Recessed | |||||
| Housing color | black, white, grey | |||||
| Warranty | 5 Years | |||||
 |
Technical Data | ||||
| Model number | SDL-10W-S02 | SDL-20W-S02 | SDL-30W-S02 | SDL-40W-S02 | |
| Watt | 10W | 20W | 30W | 40W | |
| Sizes | D90*90*H90mm | D110*110*H120 | D130*130*H135 | D160*160*H165 | |
| Input voltage | 180-240V AC/100-277V AC | ||||
| Light effect (lm/W) |
100lm/W | ||||
| CRI | 80 Ra/ 90 Ra/ 97 Ra | ||||
| CCT | 2200K/2700K/3000K/4000K/5000K/6000K | ||||
| Beam angle | 20°/45° | ||||
| Bright attennat | <3% (per year) | ||||
| Dimmable | Triac dimming/0-10V dimming/Dali dimming for choices | ||||
| Flicker free | YES | ||||
| Insallation | Recessed | ||||
| Housing color | black, white, grey | ||||
| Warranty | 5 Years | ||||
Projects
Hot Sale
Frequently Asked Questions
What warranty does the Commercial Indoor Ceiling IP20 8w 12w 15w 20w 25w 30w 40w 45w Surface Mounted Cylinder Spotlight Led Downlight come with?
The Commercial Indoor Ceiling IP20 8w 12w 15w 20w 25w 30w 40w 45w Surface Mounted Cylinder Spotlight Led Downlight carries a 5-year warranty with full coverage and no pro-rating. It is built with Tier-1 chips (Philips, Bridgelux, OSRAM) and an isolated constant-current driver with 4kV surge protection.
Can the Commercial Indoor Ceiling IP20 8w 12w 15w 20w 25w 30w 40w 45w Surface Mounted Cylinder Spotlight Led Downlight be customized for OEM/ODM projects?
Yes. LightSeek offers full OEM/ODM for the Commercial Indoor Ceiling IP20 8w 12w 15w 20w 25w 30w 40w 45w Surface Mounted Cylinder Spotlight Led Downlight — including CCT, CRI, power, finish, beam angle, and dimming protocol — backed by 3D prototyping, 24-hour aging tests, and CE/UL/SAA certification support.
What color temperature is the Commercial Indoor Ceiling IP20 8w 12w 15w 20w 25w 30w 40w 45w Surface Mounted Cylinder Spotlight Led Downlight available in?
The Commercial Indoor Ceiling IP20 8w 12w 15w 20w 25w 30w 40w 45w Surface Mounted Cylinder Spotlight Led Downlight is available in 2700K (Soft Warm White), 3500K (Warm White), 4100K (Neutral White), 5000K (Daylight), 6000K (Daylight Alert). 2700K–3000K suits warm hospitality ambiance, 4000K is typical for neutral retail and office environments, and 5000K+ for task-critical areas.
What is the CRI of the Commercial Indoor Ceiling IP20 8w 12w 15w 20w 25w 30w 40w 45w Surface Mounted Cylinder Spotlight Led Downlight?
The Commercial Indoor Ceiling IP20 8w 12w 15w 20w 25w 30w 40w 45w Surface Mounted Cylinder Spotlight Led Downlight has a CRI of 90. Ra≥80 is acceptable for general commercial use, Ra≥90 for retail and display lighting, and Ra≥95 with R9>50 for museums and premium galleries.
What beam angle does the Commercial Indoor Ceiling IP20 8w 12w 15w 20w 25w 30w 40w 45w Surface Mounted Cylinder Spotlight Led Downlight have?
The Commercial Indoor Ceiling IP20 8w 12w 15w 20w 25w 30w 40w 45w Surface Mounted Cylinder Spotlight Led Downlight has a 45 beam angle. ≤18° for accent and spotlighting, 18–36° for general lighting, and ≥36° for wide wash.
